 VC-303
Modular BassSynth Worlds first and only tb-303 synth module. 100% clone of the classic bassline synth in a modern modular format. just like a 303 only modular. original device: original signal path/schematic original part type and n.o.s. transistors used. all transistors matched for a pure sound. all on board controls and in/out. high grade spring loaded jacks - 3.5mm 'Lumberg' pcb mounted type to last a lifetime. low profile 2 board design for use within a mobile system. connections are: VCO - 1v/oct Keyboard in , Frequency Modulation CV in and Glide 0-5v in. VCF - Frequency Control CV in. ENV- Envelope CV out , Gate 0-5v in. VCA - Accent 0-5v in and Audio out. controls are the 303 standard: Waveform Select - Saw / Square (303 type). VCO Tune. VCF Cut-off , Resonance and ENV MOD. ENV Decay. VCA Accent and Volume. Frac size: 3mm black shielded FR4 faceplate with gold plated writing. (FR4 Fiberglass with ground shielding) euro size soon to come. 5U planned . 15v+/- and 12v+/- power supplies. banana jack compatible pcb Emerson type in stock. (banana hybrid - accent and kbt must be switched with 3.5mm jack) rohs lead free gold plated pcb. only high grade components are used. |
more fotos soon Price : $350 for Frac style with FR4 face euro $380 with Aluminum face Available NOW! LowStock - 23/nov Contact to buy via pay-pal Contact to pre-order Euro Version |
info(at)somaticcircuits(d0t)com
